PTFE coated fiberglass Premium Series, designed for high request industry

PTFE coated fiberglass Premier Series YS9025AJ, using basic fiberglass fabric of 7628 coated with high quality PTFE formula. The final PTFE coated fabric has excellent smooth and high gloss surface, which has superior abrasion resistance and easy release property.

ptfe fiberglass fabric

Applications of 0.25mm PTFE fiberglass fabric

PTFE coated Cloth provides a 100% non-stick surface for applications which need high temperature resistant, chemical resistant, easy release, low friction, insulation and so on.

Applications include release sheet for heat press machines, belting for food industry, Non stick baking liner or oven liner, electrical insulation and industrial processing.

0.25mm PTFE coated fiberglass is FDA & LFGB certificated, can be used in direct contact with food.

It is also widely used as a releasing sheet and laminating sheet for solar cell manufacturing, PVC or PE mold release, garment fusing, conveyor belt for paper industry, belting for tortilla and so on.

Teflon coated fiberglass cloth

ptfe coated fiberglass for solar industry

Properties of 0.25mm PTFE coated fiberglass

★ Non-stick and easy release

High gloss and low friction, result in excellent release property

★ Continuous working from -70°C – +260°C,

maximum working temperature is +327°C(short term).

★ Chemical resistant

★ Good welding property, can be easily made into belts with joint

★ Excellent tensile strength, makes the lifetime longer

Technical Data of YS9025AJ Teflon coated fiberglass fabric

Product	Product Category	Coating
PTFE GLASS FABRIC	PREMIUM SERIES	PTFE(TEFLON)

Properties	Metric	Imperial
Standard width Please ask for other widths	1000, 1250, 1500, 2000, 2600 mm	39.5, 49.3, 59.1, 78.8, 102.4 inches
Thickness	0.25 mm	0.0098 inches
Coated weight	530 g/m²	15.63 oz/yd²
PTFE content	62 %	62 %
Tensile strength	460 N/cm Warp	263 lbs/inches Warp
Tensile strength	400 N/cm Warp	229 lbs/inches Fill
Temperature resistance	-73 to +260 °C	-100 to +500 °F

Click here to download Spec of YS9025AJ-ESONE

For samples of PTFE coated fiberglass, please feel free to contact us.

Other Width is also available, you can contact us for more information

0.25mm Teflon coated cloth can be made into Black Anti-static.

Note:
Weight Tolerance g/m² = ±5
All technical data are based on average values. These values are based on test results we believes to be reliable, but they are not to be construed in any manner as warranties expressed.
